Chapter 2: Installation
Overview of the CPU Carrier Assembly
The CPU carrier assembly contains a 4th Gen Intel Xeon Scalable processor and a CPU
carrier. Carefully follow the instructions given in the installation section to place a processor
into the carrier to create a CPU carrier.
The CPU carrier assembly includes a processor and a carrier as shown below:
1. The 4th Gen Intel Xeon Scalable Processor (Component Side)
Processor (2D)
Processor (3D)
SP XCC SP MCCMax Series (HBM)
SP XCC SP MCCMax Series (HBM)
