Preface
Preface
About This Manual
This manual is written for system integrators, IT technicians and knowledgeable end users.
It provides information for the installation and use of the X13DEG-OAD motherboard.
About This Motherboard
The Supermicro X13DEG-OAD supports dual 4th Gen Intel® Xeon® Scalable Processors (
Socket E LGA 4189) with four UPIs (16GT/s max.) and a thermal design power (TDP) of up to
350W. Built with the Intel C741 chipset, the X13DEG-OAD supports up to 8TB 3DS RDIMM/
RDIMM DDR5 ECC memory with speeds up to 4800MT/s (1DPC) or 4400MT/s (2DPC) in 32
DIMM slots (Note below). This motherboard features superior I/O expandability and exibility,
including ten PCIe 5.0 x16 slots via MICRO connectors, a PCIe 5.0 advanced I/O module
(AIOM) for OCP 3.0 compliant cards, eight SATA 3.0 ports, and a dedicated BMC LAN/VGA
connector. It also o󰀨ers the most advanced data protection capability that provides TPM
(Trusted Platform Module) and hardware RoT (Root of Trust) support. The X13DEG-OAD
is optimized for future PCIe specications with exible I/O, networking, storage, and GPU
support. It is ideal for use in general purpose servers with deep learning and HPC (High
Performance Computing) applications. Please note that this motherboard is intended to be
installed and serviced by professional technicians only. For processor/memory updates,
please refer to our website at http://www.supermicro.com/products/.
Note : Memory speed support depends on the processors used in the system.
Conventions Used in the Manual
Special attention should be given to the following symbols for proper installation and to prevent
damage done to the components or injury to yourself:
Warning! Indicates that you may encounter high voltage while performing a procedure.
Warning! Indicates important information given to prevent equipment/property damage
or personal injury.
Important: Important information given to ensure proper system installation or to
relay safety precautions.
Note: Additional Information given to provide information for proper system setup.
