suprema CoreStation - Page 26

25
Product Specifications
Category Feature Specification
Electrical
Power
CoreStation
•
Voltage: 12 Vdc
•
Current: Max. 3 A
Power Supply (SMPS) AC INPUT
•
110 ~ 240 VAC, 50/60 Hz
Power Output
•
Voltage: 12 Vdc
•
Current: Max. 1.5 A
Switch input VIH
•
Max.: 5 V
•
Min.: 3 V
Switch input VIL Max.: 1V
Relay 5 A @ 30 VDC Resistive load
•
Product specifications are subject to change without notice to improve.
•
FaceStation 2 and FaceLite are available only.
1) The number of users registered without any credential data.
2) If a device with a fingerprint sensor is connected as a slave, the slave device can be used for fingerprint
authentication.
•
To have more information about CS-40 and troubleshooting section etc., please refer to the following links.
http://kb.supremainc.com/knowledge/doku.php?id=en:14_subjects_of_corestation_faq
