CAUTION
• Make sure power supply is switched o.
• All electrical installaon and repair work should be carried out by a qualied person in accordance with
current local codes or regulaons.
• Check that the electrical supply corresponds to that shown on the rang plate. If the unit is connected to
any electrical supply other than stated on the rang plate of the unit, permanent damage or unsafe
operaon of the unit may result.
• The unit must be mounted on a at vercal wall capable of supporng the full weight of the unit.
• Do not use the backplate as a guide when drilling. Ensure no pipe work (gas, water, air) or electrical
cables, wires or ductwork are located directly behind the drilling/mounng area.
1. UNPACKING
• 1.1 Place the main cover on a cloth to avoid marking its
surface.
• 1.2 Remove the (2) security screws from the main body,
using the hex key provided. Store safely.
• 1.3 Li the front cover o the main body.
CAUTION: Before installaon decide if the cable entry is to be from the rear or the above. Follow the relevant
instrucons. Do not use the backplate as a guide when drilling.
5
Mens Washroom 1300mm
Ladies Washroom 1265mm
Children 11-14yrs 1108mm
Children 8-11yrs 1028mm
Children 5-8yrs 928mm
Disabled persons 1050mm
Recommended height measurements
from the oor to top screws
