500W Boost Converter for CAR Audio - TL494
2004-2013 Sure Electronics Inc.
PS-SP12148_Ver1.0_Page 3
1.5 Quick Start
Suggested connection is shown in figure 1-2.
FIGURE 1-2 CONNECTION SCHEMATIC
Note: Please observe the following steps to complete verification so as to ensure the
products are intact during transit.
1. Open the product package and make sure the product is intact (No missing or
damaged components and no deformation.)
2. Please observe the connection schematics when connecting the 500W Boost
Converter for CAR Audio - TL494. Use nearby DC12Vand a multimeter to have a
trial. This 500W Boost Converter for CAR Audio - TL494 can be deemed as
qualified if the indicator keeps on and output voltage is the same or similar
with the value marked.
