500W BOOST CONVERTER FOR CAR AUDIO
- TL494
USER’S GUIDE
2004-2013 Sure Electronics Inc.
PS-SP12148_Ver1.0_Page 5
Following table lists all typical data of the 500W Boost Converter for CAR Audio - TL494.
TABLE 3-1 BASIC PARAMETERS
Parameter Condition Min. Typ. Max.
Supply Voltage - 11V 12V 27V
EN enabled Voltage - 12V
Output Power - - 500W
Oscillation Frequency - - 55KHZ -
Quiescent Current VIN=12V - 20mA -
Operating Temperature - 0℃ 20℃ 80℃
Storage Temperature - -20℃ 20℃ 105℃
Thermal Shutdown - - 150℃ -
Note:
Stresses beyond the listed maximum power supply voltage may cause the
permanent damage to components on board.
Chapter 3. Electrical Characteristics
