10 10
A
B
A. Flavor grids
B. Main cooking grates
C. Bread warming rack
A
B
C
Insert the avor grids into the cutouts with triangle ridges 3.
facing up.
Install main cooking grates on the ledges provided on the 4.
grill to create your cooking surface.
Attach rear igniter shield using 2 self-tapping screws.5.
Rest bread warming grate on 4 slots above cooking grid.6.
NOTE: The nished grill should look like the photo shown
on page 6 in the “Assembled Grill View” section.
Complete grill assembly
Place the side burner cap and grate on to the side burner 1.
tray.
Attach the drip pan holder to two holding brackets. Then 2.
slide drip pan into place.
A. Side burner grate
A
A. Drip pan holder
B. Drip pan
