WWW.SUREFIRE.COM
2 3
SWITCH
POSITION
LASER
OUTPUT
LASER
CLASSIFICATION
ILLUMINATOR
OUTPUT
EYE SAFE
0 OFF N/A OFF -
1 OFF N/A WHITE -
2 520nm <5mW CLASS IIIa OFF YES
3 520nm <5mW CLASS IIIa WHITE YES
4
OFF N/A OFF -
5
850nm <0.7mW CLASS I
INFRARED
YES
6
850nm <0.7mW CLASS I
OFF
YES
7 OFF N/A
INFRARED
-
GN: 520nm at <5mW
IR: 850nm at <0.7mW
CLASS IIIa LASER PRODUCT
CLASS I LASER PRODUCT
LASER SAFETY
A laser produces a very narrow beam of light, which may cause physical harm to a human being.
Subsequently, all lasers are regulated by the Federal Government. Lasers are classified by the intensity of the
light they emit. Operational safety requirements are set by the Food & Drug Administration (FDA) and the
Center for Devices & Radiological Health (CDRH) in accordance with the potential hazard to the user.
Always follow the following guidelines:
1. Never look directly into the laser beam or stare at it at close range.
2. Never shine the laser in a person’s eye at close range.
3. Do not direct the beam at anyone operating a vehicle, boat, or aircraft, as the beam appears very bright
(especially at night) in a person’s eyes, even at great distances.
4. Be aware that beam can be reflected off of mirrors or shiny surfaces.
5. Use the laser sight only for its intended purpose.
TECHNICAL SPECIFICATIONS
VISIBLE
ILLUMINATOR
INFRARED (IR)
ILLUMINATOR
VISIBLE LASER INFRARED (IR) LASER
LASER BEAM COLOR
White N/A Green No Color
LASER WAVELENGTH (NM)
N/A 850 nm 520 nm 850 nm
OUTPUT POWER (MW)
400 Lumens 300 mW <5 mW (Class IIIa) <0.7 mW (Class I)
BEAM DIAMETER AT 25M (MM)
N/A N/A 29.7 mm 29.4 mm
BEAM DIVERGENCE (MRAD)
N/A N/A 1 mrad 1 mrad
NOMINAL OCULAR HAZARD
DISTANCE (NOHD) UNAIDED, (M)*
N/A N/A 36.2 m (Class IIIa) 11.2 m (Class I)
NOMINAL OCULAR HAZARD
DISTANCE (NOHD) 5 CM AIDED, (M)*
N/A N/A 232 m (Class IIIa) 56 m (Class I)
NOMINAL OCULAR HAZARD
DISTANCE (NOHD) 8 CM AIDED, (M)*
N/A N/A 372 m (Class IIIa) 90 m (Class I)
NOMINAL OCULAR HAZARD
DISTANCE (NOHD) 12 CM AIDED, (M)*
N/A N/A 558 m (Class IIIa) 134 m (Class I)
LASER CERTIFICATION
N/A N/A Class IIIa (Training) Class I (Training)
EFFECTIVE RANGE IN DARKNESS (M)
54 meters 100 meters 200 meters 300 meters
EFFECTIVE RANGE IN DAYLIGHT (M)
N/A N/A 50 meters N/A
OPERATING TEMPERATURE
-10°C to 75°C -10°C to 75°C -10°C to 75°C -10°C to 75°C
* Based on calculation derived from ANSI Z136.1-2007 (asuming 90% optical efficiency for visible light and
70% optical efficiency for infrared laser)
