© SurgeX | Technical Support: 800-645-9721 | surgex.com Page 17
On-Line UPS User Manual
Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL
SX-BDL-1500, SX-BDL-2000
D.
E.
UPS FRONT VIEW AFTER INSTALLING 2U EARS
ASSEMBLE THE RAIL ONTO THE CABINET U-BAR WITH
SCREWS AT FRONT & BACK USING MOVABLE NUTS
