Sutron Corporation 8310 & 7310 Users Manual 8800-1125Rev. 2.7 (BETA) 4/16/2014 pg. 57
menu also includes SDI tools.
See Diagnostics for additional information.
Alarm Status
The possible values for Alarm status are:
No alarm conditions exist or all alarm conditions have
been cleared temporarily.
Means one or more output values met the alarm criteria
configured for it. The system will retain this state until the
condition is cleared. Alarms can be configured for any
output by using a device sub menu. SSP based devices all
use a common format for transmissions, and IsSSPCurData
should be set to Yes to include an output in this
transmission and to enable alarm configuration. Once this
has been set, you may enter any of the available device
menus and set Enabled to Yes, and Set TxAlarmMode to
TxIn or TxInAndOut to allows alarm notifications to be sent
to the selected device. The output will be in alarm if it is
greater than a user set HiLimit, less than a user set
LowLimit, or there is a change greater than a Rate of
Change limit.
See Understand Alarmsand Alarm Transmissions for a
complete description of Alarms and Alarm transmissions.
Note: Satlink has its own settings that control the random
transmissions. These settings are independent from those
used for Alarms.
A hint will prompt for additional action such as:
Disable -- Stops all alerts
Clear – sets status to Normal until input is measured again.
Logged Data
Logged Data is a sub-menu that displays all available log files, allowing the user to select a view.
By default, the data.log is highlighted as it normally contains data collected by the system.
Once a logged is selected, the data is displayed as shown below:
