Sutron Corporation 8310 & 7310 Users Manual 8800-1125Rev. 2.7 (BETA) 4/16/2014 pg. 63
Mx[*]: name status >
Each measurement is listed with its ID (e.g.M1), “*” if it is being measured, and information on
the status of the measurement. Status can be one of the following values:
Executing – currently being measured
Next: HH:MM:SS – waiting until the specified time to be measured.
Sample x of y – measurement includes averaging or an accumulation, and the system has taken
x out of a total of y samples.
Press RIGHT to view/change the details of the selected measurement.
Add Measurement
This function adds a new measurement to the system.
Delete Measurement
This function deletes a measurement from the system. A menu of the available measurements
is displayed and a measurement is deleted by selecting a measurement and pressing SET or
ENTER.
Copy Measurement
This function makes a copy of an existing measurement. Select the measurement you wish to
make a copy of, and the system will prompt you for a new name, and new mux channels if being
used.
Move Measurement
This function may be used to rearrange the order of measurements. Select the measurement
you wish to move and then by pressing the UP and DOWN arrows a new position may be
selected.
Station Setup/Measurements/Mx
This menu gives all the information needed to make a specific measurement. A typical display is
provided below. The “Enable” is a master on/off switch that allows you to have measurements
set up but not active in the system. Measurement Types (MeasType) have been defined for
instantaneous measurements, averages, vector averages, and others. Depending on MeasType
selected, you will have additional menu items to specify the times, intervals and sensor(s) you
want to measure.
M1*: TEMP
MeasName TEMP
Enable Yes
MeasType Average
Interval 00:01:00
Time 00:00:10
SampleInterval 00:00:10
SampleDuration 00:01:00
M1.I1: InputType InternalTemp
