Engine General Information and Diagnosis: 1A-20
4WHT/RED
CAN (high) communication line
(active high signal) to ABS
hydraulic unit / control module
assembly
34 — —
5 PPL/WHT
12 V serial communication line
of data link connector
35 — —
6BLK/WHT
Cruise control main switch
signal (if equipped with cruise
control system)
36 — —
7BLU
Clutch pedal position switch
signal (if equipped with cruise
control system)
37 — —
8YEL/GRN
Brake pedal position switch (if
equipped with cruise control
system)
38 — —
9— — 39— —
10——40——
11——41——
12 YEL
Diagnosis switch terminal (if
equipped)
42 — —
13 PNK/BLU
Clock signal for immobilizer
coil antenna (if equipped)
43 — —
14——44——
15 WHT/GRN Fuel pump relay output 45 — —
16 BLU/BLK Main power supply 46 RED/BLK
Radiator cooling fan relay No.1
output
17 GRN
Power supply of throttle
actuator drive circuit
47 RED
Radiator cooling fan relay No.2
output
18 — — 48 RED/YEL
Radiator cooling fan relay No.3
output
19 WHT/BLU
CAN (low) communication line
(active low signal) to ABS
hydraulic unit / control module
assembly
49 PNK
A/C compressor relay output (if
equipped with A/C)
20 GRN/WHT Stop lamp switch signal 50 BLU/ORN
Throttle actuator control relay
output
21 BLK/YEL
Cruise control command
switch ground (if equipped with
cruise control system)
51 BLU/YEL
Ground for accelerator pedal
position (APP) sensor (sub)
22 LT GRN
Cruise control command
switch signal (if equipped with
cruise control system)
52 BLU/GRN
Accelerator pedal position
(APP) sensor (sub) signal
23 — — 53 ORN/BLU
Output for 5 V power source of
accelerator pedal position
(APP) sensor (sub)
24 YEL/RED Fuel level sensor signal 54 ORN
Ground for accelerator pedal
position (APP) sensor (main)
25 — — 55 WHT/BLU
Accelerator pedal position
(APP) sensor (main) signal
26 — — 56 WHT
Output for 5 V power source of
accelerator pedal position
(APP) sensor (main)
27——57——
28 GRY/BLU
Serial communication line for
immobilizer coil antenna (if
equipped)
58 — —
29 BLK/WHT Ignition switch signal 59 — —
30 — — 60 BLU Main power supply relay output
Terminal Wire color Circuit Terminal Wire color Circuit
