Suzuki GSX-S1000 User Manual

6-7
3. Place a cloth between the meter
panel and the fuel tank to prevent
damage to the fuel tank.
4. Remove the meter panel starting
from the rear end portion. Lightly
press the fairing toward the out-
side of the motorcycle (in the
direction of the arrow), and lift the
mating surface on the rear end of
the meter panel above the fairing.
Disengage the hook (marked with
a dotted circle) on the side of the
meter panel.
NOTICE
When removing the meter panel,
the bolt mounting part on the rear
end may cause damage to the fuel
tank and fairing.
When removing the meter panel,
use a cloth to prevent scratches,
and carefully remove the panel
using the following procedure.

Suzuki GSX-S1000 Specifications

General

Engine Type	4-stroke, 4-cylinder, liquid-cooled, DOHC
Bore x Stroke	73.4 mm x 59.0 mm
Compression Ratio	12.2:1
Fuel System	Fuel injection
Starter	Electric
Transmission	6-speed constant mesh
Final Drive	Chain
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Disc, twin
Rear Brakes	Disc
Front Tire	120/70ZR17M/C (58W), tubeless
Rear Tire	190/50ZR17M/C (73W), tubeless
Displacement	999 cm3
Overall Length	2115 mm
Overall Width	810 mm
Overall Height	1080 mm
Wheelbase	1460 mm
Ground Clearance	140 mm
Seat Height	810 mm
Curb Weight	214 kg
Fuel Tank Capacity	19 L (5.0 US gal)
