Suzuki GSX-S150 User Manual

8-2
STORAGE PROCEDURE AND
MOTORCYCLE CLEANING
STORAGE PROCEDURE
If your motorcycle is to be left unused for an
extended period of time, it needs special
servicing requiring appropriate materials,
equipment and skill. For this reason, Suzuki
recommends that you trust this maintenance
work to your Suzuki dealer. If you wish to
service the machine for storage yourself, fol-
low the general guidelines below:
MOTORCYCLE
Clean the entire motorcycle. Place the
motorcycle on the side stand on a firm, flat
surface where it will not fall over.
FUEL
1. Fill the fuel tank to the top with fuel
mixed with the amount of gasoline stabi-
lizer recommended by the stabilizer
manufacturer.
2. Run the engine for a few minutes until
the stabilized gasoline fills the fuel injec-
tion system.
ENGINE
1. Pour one tablespoon of motor oil into
each spark plug hole. Reinstall the spark
plug and crank the engine a few times.
2. Drain the engine oil thoroughly and refill
the crankcase with fresh engine oil all
the way up to the filler hole.
3. Cover the air cleaner intake and the muf-
fler outlet with oily rags to prevent humid-
ity from entering.
BATTERY
1. Remove the battery from the motorcycle
by referring to the BATTERY section.

Suzuki GSX-S150 Specifications

General

Engine Type	4-Stroke, Liquid-Cooled, DOHC
Displacement	147.3 cc
Bore x Stroke	62.0 mm x 48.8 mm
Compression Ratio	11.5:1
Fuel System	Fuel injection
Starter	Electric
Transmission	6-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Front Brake	Disc
Rear Brake	Disc
Seat Height	785 mm
Rear Suspension	coil spring, oil damped
Fuel Tank Capacity	11 liters
Overall Length	2020 mm
Overall Width	745 mm
Overall Height	1040 mm
Wheelbase	1, 300 mm
Curb Weight	131 kg
Front Tire	90/80-17M/C, tubeless
Rear Tire	130/70-17M/C, tubeless
