(Continued)
3. at t a c h i n g t h e pr i v a c Y Bo a r D
3. at t ac h i n g t h e pr i v a c Y Bo a r D
A. Align the Privacy Board to the backside
of the Leg Stands.
B. Align the holes in the Privacy Board with the Threaded
Holes of the Leg Bracket. Install using two 1/2" Machine Screws
(E3) into the Privacy Board.
IMPORTANT!
Do not tighten them at this time.
C. Align the 4 small holes at the bottom of the Privacy
Board with the holes in the Pedal Board. Install
four 1/2” Wood Screws (E4) prior to tightening them.
IMPORTANT!
Do not over tighten the screws.
4. at t a c h i n g t h e pi a n o
t o t h e St a n D
A. Using two people, lift the Piano onto the Leg Stands
and Pedal Board assembly.
To Next Page
