Suzuki Intruder VZ800 User Manual

9-38 ELECTRICAL SYSTEM
NOTE:
If no air bubbles are coming up from a filler port, tap the bottom
of the electrolyte container two or three times.
Never remove the container from the battery.
• After confirming that the electrolyte has entered the battery
completely, remove the electrolyte containers from the bat-
tery. Wait for about more than 20 minutes.
• Insert the caps 7 into the filler holes, pressing in firmly so that
the top of the caps do not protrude above the upper surface of
the battery’s top cover.

• For initial charging, use the charger specially designed for MF
battery.

* Never use anything except the specified battery.
* Once the caps have been installed to the battery, do
not remove the caps.
* Do not tap the caps with a tool such as hammer
when installing them.
INCORRECT
CORRECT
* For charging the battery, make sure to use the
charger specially designed for MF battery. Other-
wise, the battery may be overcharged resulting in
shortened service life.
* Do not remove the cap during charging.
* Position the battery with the cap facing upward dur-
ing charging.
SAMPLE

Suzuki Intruder VZ800 Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC, 45-degree V-twin
Displacement	805 cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Rear Brake	Drum brake
Seat Height	700 mm (27.6 in)
Front Brake	Disc brake
Rear Tire	170/80-15M/C 77H, tube type
Fuel Tank Capacity	15.5 L (4.1 US gallons)
