Technical Specification
Cooking Hob SVI6391 SVI200
Cooking Zones
3 Zones 2 Zones
Supply Voltage
220-240V~ 220-240V~
Installed Electric
Power
6200W 3600W
Product Size
D×W×H(mm)
590×520×60 290×520×60
Building-in
Dimensions A×B
(mm)
×490 270×490
Weight and Dimensions are approximate. Because we continually strive to
improve our products we may change specifications and designs without prior
notice.
Installation
Selection of installation equipment
Cut out the work surface according to the sizes shown in the drawing.
For the purpose of installation and use, a minimum of 5 cm space shall be
preserved around the hole.
Be sure the thickness of the work surface is at least 30mm. Please select
heat-resistant work surface material to avoid larger deformation caused by the
heat radiation from the hotplate. As shown below:
560
Model L(mm) W(mm) H(mm) D(mm) A(mm) B(mm) X(mm)
SVI6391 590 520 60 56 560 490 50 mini
SVI200 290 520 60 56 270 490 50 mini
