REMOVAL
1) Discharge the high voltage capacitor.
2) Disconnect the leadwire from magnetron, high voltage
transformer, and capacitor.
3) Remove the screw holding the high voltage
transformer to the baseplate.
1) Discharge the high voltage capacitor.
2) Disconnect the leadwire from fan motor, noise filter
and high voltage capacitor.
3) Remove the two screws holding the orifice
oven cavity and remove the high
voltage
earth screw.
4) Remove the screw of the capacitor bracket.
5) Remove the two screws holding the fan motor ASS’Y
to the Orifice
to the
diode
ASSEMBLY REMOVAL
ASS’Y
.
ASS’Y
1) Discharge the high voltage capacitor.
2) Disconnect the leadwire from fan motor, noise filter
and high voltage capacitor.
cavity
and
remove
the
high
voltage
diode
earth screw.
4) Remove the screw holding the high voltage capacitor
bracket.
3)
Remove the screw holding the Orifice
the oven
to
ASS’Y
1) Disconnect the leadwire from the PCB SUB ASS
’Y.
2) Remove the screws for the earth and securing the
control panel.
3) Lift control panel ASS’Y from the oven by the tab
unhooked.
1) Open the door.
CAUTION : Be careful not to damage Door C
by screwdriver.
3) Lift up and pull the door.
NOTE:
1. After replacing the door, be sure to check that the
primary switch, monitor switch, and secondary switch
operate normally.
2. After replacing the door, check for microwave energy
leakage with a survey meter. Microwave energy must
be below the limit of 5 mW/cm
2
. (with a 275 ml water
load)
3. When mounting the door assembly to the oven
assembly, be sure to adjust the door assembly parallel
to the chassis. Also adjust so the door has no play
between the inner door surface and oven frame
assembly. If the door assembly is not mounted
properly, microwaves may leak from the clearance
between the door and the oven.
to the Cavity Ass'y.
2) Remove two screws holding the Hinge
Remove door Assembly
6
Control Panel Assembly
Door Assembly
①
②
③
①
②
③
H.V. Transformer
H.V. Capacitor
H.V. Diode
4. CONTROL PANEL ASSEMBLY REMOVAL
5. DOOR ASSEMBLY REMOVAL
6. HIGH VOLTAGE TRANSFORMER
7.
8. H.V. CAPACITOR AND DIODE REMOVAL
ORIFICE
