Sven PS-55 - Page 5

ENG
5
PS-55
User Manual
•Turn on both speakers (long press button a) and select Bluetooth mode. On both speak-
ers, indicator d will ash blue.
•On one of the speakers, press button a twice. The speakers will connect with each other.
Note. At the subsequent inclusion of both speakers, they will be connected automatically.
TECHNICAL SPECIFICATIONS
Parameter, measurement unit Value
Frequency response, Hz
120–20 000
Output power (RMS), W 5
Speaker diameter, mm Ø 45
Rated current consumption, A 0.07
Battery capacity, mA*h 600
Power supply USB ⎓ 5V
Dimensions, mm: 72 × 72 × 108
Weight, kg 230
Notes. Technical specications given in this table are supplemental information
and cannot give occasion to claims. Technical specications and package contents
aresubject tochange without notice due to the improvement of SVEN production.
Fig. 2. Connection diagram
USB to micro USB
power cable
USB jack
Mini-jack to mini-jack
signal cable
Mobile
device
PC
Socket
