Sven SPS-705 - Preparation and Operation

b
c
e
d
f
a
Control panel
a LED operation mode
b VOLUME: volume control knob
c TREBLE: treble control knob
d BASS: bass control knob
e : headphone jack
f : AUX/BT switch mode button
5. PREPARATION AND OPERATION
Speaker placement
• Place the speakers symmetrically to the listener at least
one meter away.
• Place MSS far away from monitors and TV sets, as insi-
gnificant image distortion in these supersensitive devices
is possible.
MSS Connecting
SPS-614/SPS-701/SPS-705 Multimedia Speaker Systems
can be connected to virtually any audio source: DVD/CD, PC
sound card, etc. (see connection diagram in Fig. 2).
~230V/50Hz
AUDIO INPUT
OUTPUT
R L
L
POWER SWITCH
ON
OFF
Fig. 2. Connection diagram
or
CD
PC
DVD
Player
Active
speaker
Passive
speaker
2RCA to 2RCA
signal cable
2RCA to mini-jack
signal cable
Fig. 1. Control panel
16
ENG
2.0 Multimedia Speaker System
