FOURTIFY HARDWARE CONNECTION
LAN1WAN LAN2 LAN3 LAN4
Fourtify Hardware Connection Diagram
3 x BNC and Power
extension cable
Main Camera
(Wi-Fi)
3 x Expansion Camera
Power splitter
Router
(not included)
Power extension cable
Power adapter
* The Ethernet connector provides an optional wired connection to your router as a backup connection
after the main camera has been configured to connect to your Wi-Fi network using the app.
OPTIONAL
Video and Power cable
Video Video Video Power Ethernet*
