QUICK REFERENCE/START GUIDE

CFE Plus (WiFi)

Instruction# 1697

Version# 1.07

Part# -

EAN# SE-10 & SE-11

Author: KW

SUPPLIED IN SET

The following products are supplied in the CFE-Plus set:

CFE-Plus

CPU

(OBD Male Dongle)

CFE-Plus

Configuration cable

(OBD Female / USB)

CFE-Plus

Usb cable

TECHNICAL DATA

Power source : 13.4V (9V-18V allowable), Negative GND, Current consumption active : ~300mA, Current con-

sumption “sleep” (ignition off) ~2mA, Dimensions (WxHxD cm) 5x3x2, Weight CPU (gram) 150. Requires Win-

dows PC (Windows 7,8 or 10) for configuration changes. CFE-Plus connects to both Low-speed canbus and

High-speed canbus.

WARRANTY

The CFE-Plus comes with a full year of warranty on the hardware (CPU). Since the functions will extend periodi-

cally, new functions will become available, presented in new firmware. These updates might contain bugs

(software bugs). A full warranty description is available (and presented to you for approval) online, when fin-

ishing a sales transaction with us.

FUNCTION OVERVIEW

Please see current functionality availability here:

https://www.swedesolutions.com/cfe-capabilities/
