Continue with Step 7 (for all P3’s 2011+)
Step 5: (For cars WITH Sensus Connect only!) Remove the screws and slide out the IHU. Connect the harness(es) supplied
with the set (or bought separately) to the BROWN and/or GREEN connector.
Generally : Reverse camera goes to BROWN connector, front camera or any other additional video usage goes to GREEN
connector. In case a connector is already taken (used), just remove the installed connector. (In such case some pre-wiring is
available in the car, but for this installation that pre-wiring will not be used!)
Step 6: (For cars WITH Sensus Connect only!) this step number is not available for cars with Sensus Connect,
continue with step 7.
Step 7: (For V40, go to step 9) Guide wires downwards, preferably on the right hand side. Then fold the carpet away
from the tunnel and find the connector as shown.
