SwedeSolutions CFE Plus - Connect Power and Ground; Remove Center Console Carpet (V40)

INSTALLATION MANUAL
CFE-Plus MY 01-04
Harness
© 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com
Instruction# 1697
Version# 1.06
Part# ntbp
EAN#
Author: KW
Step 8: Use the supplied Quick connects to connect the 12v+ (Connect to Green-orange) and GND (connect to Green-black)
(For Camera power supply) and fold back the carpet once done. The mini-connector should stay available to connect the
camera to.
(camera hookup : see specific manual about camera hookup).
The next steps only V40!
Step 9: First remove the carpet from the center console.
