3.3 Integer Value (RO): IV R
Object
Instance
Object Name Min/Max
17 Changeover Status 0-1
Automatic changeover between heating and cooling (0=inactive, 1=heating, 2=cooling)
18 Defrost Status 0-2
0=IDLE, 1=ACTIVE, 2=STOP to drain water
19 Digital Outputs Status 0-65536
Contains a bit for each of the digital outputs:
bit0="AL1 (alarm)"
bit1="BYPASS 1 (For on/o bypass: 0=closed/o 1=open/on. For prop_bypass: 0=down
1=up"
bit2="BYPASS 2 (For on/o bypass: always on. For prop_bypass: 0=stop 1=run)"
bit3="CT"
bit4="KWin"
bit5="KWout"
bit6="OR1 SAT “pressure alarm””
bit7="OR2 SAT “fan on”"
bit8="OR3 SAT “water pump NV”"
bit9="OR4 SAT “bypass on”"
bit10="SATBA WP"
bit11="SATBA OUT9 KWext"
20 OUT INT ELECT PREHEAT 0-100
Output percentage for the power control of the electrical preheater
21 OUT INT ELECT POSTHEAT 0-100
Output percentage for the power control of the electrical postheater inside the unit
22 OUT EXT ELECT POSTHEAT 0-100
Output percentage for the power control of the electrical postheater external to the unit
23 CP SENSOR MODBUS SUPPLY 0-9999 [Pa]
Pressure measured by the Modbus sensor located on the supply duct
24 CP SENSOR MODBUS EXHAUST 0-9999 [Pa]
Pressure measured by the Modbus sensor located on the exhaust duct
