SWF MAS-12 - Back Bracket Assembly; Bottom Bracket Assembly

5
① Stand up the left and right legs together as
shown in the picture to assemble the Back
Bracket (Connecting Plate).
② Place the Back Bracket on the stand (left)
(right) and tighten it firmly using 4 big bolts and
washers each.
◇ Big Bolts, Washers, Back Bracket
① With the casters of the stand facing
upward as shown in the picture, then place
the Bottom Bracket on the legs.
② Tighten the Bottom Bracket firmly using
two big bolts and washers each.
4) Assembling the Bottom Bracket
3) Assembling the Back Bracket
◇ Big Bolts, Washers, Bottom Bracket
2. Stand Assembly
