① Insert Spool Stand to Spool Stand Stud.(Insert Spool Stand "A" to Tension Plate )
② Fix Angle Base to Angle "D".(connect it with M4L10 Bolt)
③ Connect Spool Stand with Angle Set.(Insert Spool Stand to Angle Frame groove)
④ Fix Angle Frame Hall to Spoon Stand with Fix Bolt.(with 4mm T-Wrench)
⑤ Fix Spool Stand Stud Bolt to Spool Stand .(with 2.5mm L-wrench)
※ If Spool Stand/Angle and Fixed Bolt are not connected correctly, vibration from Spool Stand and Angle
seems like harder than real.
2)Attach OP BOX and connect Cable.
#Not for less than Y-Storke 1200mm model (Because it is not seperated from Op.Box)
Page 8 Of 17 (주)SUNSTAR SWF CS Center
