MOTORHOME CARE
121
Select 184 Double bed
make up instructions
(with safety seat)
Step 1
Use the release catch on the seat side and pull
the seat base out, complete with cushion. The
base cushion will drop down and rest on the
pull out.
Step 2
Lift the kitchen work top and remove the infill
cushion for the seat base. Note: This cushion
does not have rails on the underside. Place on
the seat base.
Step 3
Remove the other 2 cushion make up pieces
from the kitchen storage and slide out the
support leg from the base of the storage area.
Step 4
Select the cushion make up piece with the
tabs on the metal rails. Position the cushion
on the slide out leg ensuring that metal rail sits
between the nylon spacers on the slide out
leg. The opposite side will sit on the Forward
facing seat pullout.
SELECT 184 DOUBLE BED MAKE UP
INSTRUCTIONS
