84
SWIFT COMMAND POWER CONTROL SYSTEM
5 Technical Data & Approvals
5.1 Equipment – EC652, EC653, EC800,
EC635 & PX300
Outline Specification
INPUT 230V 230 Volts / 0 to 16 Amps + / - 10%
OUTPUT 230V RCD protected, 2 x MCB outputs of 10A & 1 x
MCB output of 16A
Separate switched channels for heating system
and charger
INPUT 12V 2 x 20A battery inputs via 2 x 4 way connectors
SOLAR INPUT 1 X Dedicated solar panel input capable of
supporting 10A of solar power input (typically
180 to 200W) via a 2 way connector
Check the solar
panel rating plate to
ensure the maximum
current is <= 10A
OUTPUT 12V 25A total output via multiple switched channels
protected by 13 fused outputs
Integrated
CHARGER
Input 220-240 Volts AC +/- 10%, Frequency 50
Hz +/- 6%, Current 3A max.
DC Output 13.6 to 14.4 Volts nominal, Current
25 Amps max (300 Watts).
Signal INPUT 4 x Fresh water level, 4 x Waste water level,
1 x Engine running, plus multiple vehicle
connections, sensor inputs for temperature &
humidity
Fresh water negative
sensed
Waste water
negative sensed
Data IN / OUT CANBUS Data communication and power to
Control Panel via 6 way connector
CI-Bus Data communication to CI-Bus enabled
devices via RJ11/12 connector
IP rating IP31
Operating
temperature
Ambient 0 to 35° Celsius
Charger case temperature with full load 65° C
Max
Automatic shutdown
and restart if
overheated /
overloaded
Dimensions
EC601, EC602,
EC652 & EC653 PSU
Overall size (HxWxD) 180 x 305 x 135mm
Clearances 75mm above, 50mm left & right
Weight 3.8 Kg
EC800 Control Panel Overall size (HxWxD) 125 x 279 x 25mm
Cut-out size (HxW) 108 x 173mm + switch area
Fixing centres
250mm X 74mm
Weight 380g
EC635 Comms
Module
Overall size (HxWxD) 55 x 116 x 85mm Weight 550g
EC840 Sensor Overall size (HxWxD) 20 x 35 x 38mm Weight 10g
