Swift Kon-tiki User Manual

Lower ventilation grille (L200
Upper ventilation grille with flue vent
( L100)
1
23
72
Equipment Details
Switching off gas operation
If the refrigerator is to be taken out of service
for an extended period of time, the on-board
shut-off valve and the cylinder valve must be
closed.
WINTER OPERATION
1. Check that the ventilation grills and the
extractor have not been blocked by snow,
leaves or similar.
2. When the ambient temperature falls
below +8°C, the optional winter covers
should be fitted. This protects the unit
from excessively cold air.
3. Affix the cover and fasten it.
Tip: It is also recommended that the winter
covers should be used when the vehicle is
taken out of service for an extended period
of time.
INTERIOR LIGHT
Changing the light bulbs
1. Remove cover.
2. Detach
defective
light bulb.
3. Fit new light
bulb

Swift Kon-tiki Specifications

General

Vehicle Type	Motorhome
Base Vehicle	Fiat Ducato
Width	2.35 m
Fuel Tank	90 L
Layout	Fixed island bed
Engine Options	2.3L Multijet
Power	140-180 hp
Transmission Options	Manual, Automatic
Berths	4
Seatbelts	4
Fresh Water Tank	100 L
Heating	Truma Combi
Height	2.90 m
Gross Vehicle Weight	3500 kg
Solar Panel	Optional
