Swift Kon-tiki User Manual

73
Equipment Details
4
1
2
3
4
5
7
6
4. Clip the cover
back in place.
Note: For 12V
DC : 1 light bulb
12V, 2W
Please contact Dometic Service Centres for
replacement light bulbs.
CHANGING THE DECOR PANEL
1. Open the door and loosen the hinge
screw.
2. Take off the door by moving it upwards.
3. Unscrew the door strip (3 screws).
4. Remove the decor plate and insert a new
decor plate.
5. Screw the door strip back in position.
6. Put the door back on.
7. Tighten the hinge screw.
Dimensions of the panels in mm:
Model Height Width Thickness
RM 7271 /..75 713+/-1 453.5+/-1 3.2
RM 7361 /..65 713+/-1 453.5+/-1 3.2
RM 7291 /..95 718+/-1 491.5+/-1 3.2
RM 7401 /..05 718+/-1 491.5+/-1 3.2
Changing the doorhang
It is not always possible to change the door
when the refrigerator is installed.
1. Open the door, unscrew the hinge
screw and keep it to hand.
2. Take off the door by moving it upwards.
3. Attach the door.
4. Screw the hinge screw back in.

Swift Kon-tiki Specifications

General

Vehicle Type	Motorhome
Base Vehicle	Fiat Ducato
Width	2.35 m
Fuel Tank	90 L
Layout	Fixed island bed
Engine Options	2.3L Multijet
Power	140-180 hp
Transmission Options	Manual, Automatic
Berths	4
Seatbelts	4
Fresh Water Tank	100 L
Heating	Truma Combi
Height	2.90 m
Gross Vehicle Weight	3500 kg
Solar Panel	Optional
