MV-1046-9-2016
.
Swim & Fun Scandinavia
.
info@swim-fun.dk
.
www.swim-fun.com
© All rights reserved Swim & Fun Scandinavia ApS 2016
Page 33
4. Specications
Rated input voltage and frequency 110V/60Hz;220V/50Hz
Output Voltage DC24V
Rated output power 150W
Working cycle 1h/1.5h/2h
Cable length 9 meter
Maximum cleaning area 25m²
Filtering capacity 18m³/h
Filter density 180μm
For poolwater types Chlorine and saltwater
Water temperature for use of cleaner 10°C - 35°C
Creeping speed 20m/min
IP Grade Cleaner IPX8
IP Grade power supply unit IPX4
Working environment temperature for power unit 10°C - 40°C
Maximum pool depth 2m
Climb slope Maximum 15°C
5. Cleaner Structure
Top cover
Filter tray
Chassis
Assemble the accordingly
