2 CYCLE
Stop after 1 hour working,
Moving direction reverses
every 16 seconds, suit for
small swimming pool
Stop after 1.5 hour working,
Moving direction reverses
every 25 seconds, suit for
medium swimming pool
Stop after 2 hour working,
Moving direction reverses
every 35 seconds, suit for
large swimming pool
3 INDICATOR
Flash by corresponding cycle,
all indicators ash after one
cycle nish.
6.3 Function and adjustment of nozzle
There are two nozzles on the cleaner, one of them opens once the other closes. Water ows out
through the opening nozzle to thrust the cleaner move forward. Adjust the nozzle by rotating it to
control the moving path.
6.3.1 : Settings of nozzle
Nozzle angle from 0° to 40°
Cleaner moves in approximately straight line when nozzles in position 0°.
Cleaner moves in a more curved line at a larger angle from 0°—40°.
