swimmax 07 - Page 23

- 22 -
Model: Swimmax 07 / Swimmax 09
No.
Name of parts
No.
Name of parts
1
Ambient temp. sensor clip
31
Low pressure switch
2
Ambient temp. sensor
32
4-way valve coil
3
Evaporator
33
4-way valve to exchanger
4
Top frame
34
Capillary
5
Pillar
35
Exchanger to capillary
6
Fan motor bracket
36
4-way valve to evaporator piping
7
Left panel
37
High pressure switch
8
Fan motor
38
Four-way valve
9
Fan blade
39
Discharge pipe
10
Evaporator bracket
40
Pipe
11
Ventilation grid
41
Exchanger temperature sensor
clip
12
Controller box cover
42
Water outlet temp. sensor
13
Controller
43
Sealing ring
14
Waterproof controller box
44
water switch
15
Panel support
45
Rubber ring on water
connection
16
Isolation panel
46
Red rubber ring
17
Compressor
47
Water connection sets
18
Front panel
48
Blue rubber ring
19
Base tray
49
Titanium heat exchanger
20
Terminal box
50
Water inlet temp. sensor
21
Right panel
51
drainage plug
22
clip
52
Electrical box cover
23
5- ways terminal block
53
Compressor capacitor
24
Wiring cover
54
Capacitor clip
25
Clip
55
transformer
26
Evaporator temperature
sensor
56
Fan capacitor
27
High pressure gauge
57
PCB
28
Back panel
58
Liner
29
Top cover
59
Electrical box
30
Gas return piping
