Model Swimmax 13.5
No.
Name of parts
No.
Name of parts
1
Evaporator
31
4-way valve coil
2
Top frame
32
Four-way valve
3
Pillar
33
High pressure switch
4
Evaporator bracket
34
Pipe
5
Fan motor bracket
35
Low pressure switch
6
Fan motor
36
Gas return piping
7
Fan blade
37
4-way valve to exchanger
8
Left panel
38
Exchanger to capillary
9
Ventilation grid
39
Capillary
10
Controller box cover
40
4-way valve to evaporator piping
11
Controller
41
Exchanger temperature sensor
clip
12
Waterproof controller box
42
Water outlet temp. sensor
13
Front panel
43
Sealing ring
14
Panel support
44
water flow switch
15
Base tray
45
Rubber ring on water
connection
16
Compressor
46
Red rubber ring
17
Terminal board
47
Water connection sets
18
High pressure gauge
48
Blue rubber ring
19
Clip
49
Titanium heat exchanger
20
5- ways terminal block
50
Water inlet temp. sensor
21
Wiring cover
51
drainage plug
22
Right panel
52
Electrical box cover
23
Isolation panel
53
Capacitor clip
24
Clip
54
Compressor capacitor
25
Evaporator temperature
sensor
55
PCB
26
Ambient temp. sensor
56
Fan capacitor
27
Ambient temp. sensor clip
57
transformer
28
Back panel
58
AC contactor
29
Top cover
59
Liner
30
Discharge pipe
60
Electrical box
