Swiss Madison Cascade - Frame Preparation and Assembly

FREESTANDING VANITY INSTALLATION
Parts for Reference:
1. Left side panel
2. Middle panel
3. Right side panel
4. Rear top bar
5. Rear bottom bar
6. Front cross bar
7. Bottom panel
8. Left side door
9. Middle door
10. Right side door
11. Front & back leg apron
12. Leg apron side rail
A. Cam bolt lock M6 X 35mm (33)
B. Cam lock 15mm x 12mm (33)
C. Wood dowel 8mm x 30mm (20)
D. Screw M4 x 35mm (4)
E. Hinge (4)
F. Metal corner bracket (2)
G. Short screw M4 x 14 mm (52)
H. Plastic anchor M8 x 40mm (4)
I. Long screw M6 x 60mm (4)
J. Door pad (6)
K. Middle door hinge (2)
A F
G
H
I
J
K
B
C
D
E
Prepare Frame
1
INSTALLATION:
1
2
3
7
7
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
180°
A
A
A
A
A
A
A
7
2
3
4
6
1
8
9
10
11
12
12
A x 29
4
5
5
11
