swissonic Basic Router MKII - Technical Specifications; Hardware and Connectivity Specifications

8 Technical specications
Input connections Power supply Connection socket for the plug-in power supply
WAN port 1 × RJ45 socket to connect to the Internet
Output connections LAN ports 4 × RJ45 socket to connect to local network devices
Frequency range 2.4 GHz and 5 GHz
Max. transmission power 100 mW
Range in clear eld of vision up to 100 m indoor, up to 300 m outdoor
Power supply
External power adapter, 100 - 240 V 50/60 Hz
Operating voltage
9 V / 0.8 A, centre positive
Dimensions (W × H × D) 175 mm × 37 mm × 128 mm, with folded antennas
175 mm × 179 mm × 128 mm, with unfolded antennas
Network cable length 90 cm
Weight 232 g (incl. antennas)
Ambient conditions Temperature range 0 °C…40 °C
Relative humidity 20 %…80 % (non-condensing)
Default IP address 192.168.1.1
Technical specications
Basic Router MKII
29
Router
