swissonic USB Studio D - Specifications; Microphone Inputs; Instrument Inputs; Phono Input

Specifications Microphone Inputs
Input impedance 1kΩ, Balanced
Gain range Off to >+50 dB
Phantom power +48±4% VDC, IEC268-15
Max. input level –5/–35dBu,
+20/+50dB Gain
Equivalent input noise –125dBu, 20k BW, 50dB
gain, Rs=150 Ω
Frequency response 20–20000 Hz@–0,1dB,
all gains
THD+ Noise 0,005%, Gain = 20dB
0,01%, Gain = 50dB
Instrument Inputs
Input impedance 20MΩ || 60pF
Gain range Off to >+50dB
Max input level –5/–35dBu, +20/+50dB in
Equivalent input noise –110dBu, 20k BW, 50dB
gain, Rs=600 Ω
THD+Noise 0,02%, 20k BW, 50dB
gain, Rs=600 Ω
Frequency response 15–40000Hz@–3dB
Phono Input
Input impedance 50kΩ
RIAA correction error <1dB, 20–20000Hz
Gain 34dB@1kHz
THD+Noise 0,02%@1kHz, 20k BW
Line Inputs
Input impedance 50 kΩ
Gain range Off to 0dB
Clipping level >+20dBu
Line Outputs
Output impedance 100Ω
Clipping level >+20dBu
Any one line input
to any line output
THD+Noise 0,003%,
Level=max, rl=600Ω
SNR 100dB, Ref=+10dBu
Frequency response 20–20000Hz@–0,1dB
14
