Operating Elements
37
3 Operating Elements
The buttons in this operating manual are subsequently depicted
with a uniform contour. Therefore, slight deviations in the appea-
rance of the symbols on the walkie−talkie buttons compared to
those depicted here are possible.
Walkie-talkie
1 Antenna
2 Display
3 Transmit ringing tones
4 Volume,
Channel, scroll down
5 Microphone
6 Loudspeaker
7 Volume,
Channel, scroll up
8 On / Off,
Channel setting
9 PTT − Talk button
Display
1 Transmitting
2 Channel / Volume
3 Receiving
4 CH = Channel
LE = Volume
5 Weak battery
1
2
3
4
5
