SWorkz S35-4e EVO - Page 14

14
15
14
BAG
E1
OPTION:
SW-330795
S35-Aluminum Rear Lower Fully Adjustable
Toe-In Block (+0.5 Degree)
228001DG (#2 #3 #4)
330399B
108005
228001DG (#2 #3 #4)
108008
M3x35mm FH/ST HEX Screw
x2
338113
228006
106002
338056
330770
338056
108008
108005
M3x14mm FH/ST HEX Screw
x2
108001
M3x12mm FH/ST HEX Screw
x4
108001
106002
M3x10mm Hex Socket OH/TP Screw
x1
338056
S35-4 Series Lower Arm Hinge Pin (68.5mm)
x2
PRO TIP:
The S35-4 EVO Aluminum Rear Lower Fully
Adjustable Toe-In Block (330770) can use 3
types of square inserts to get 1.0/2.0/3.0 3
different toe in angles. Also plus 3 different
rear lower arm kick up degrees.
PRO TIP:
228001DG-2 S35-4 Series Rear Lower Arm Holder Square Insert (+1/+1)
228001DG-3 S35-4 Series Rear Lower Arm Holder Square Insert (0/+1)
228001DG-4 S35-4 Series Rear Lower Arm Holder Square Insert (0)
