SWorkz S35-4e EVO - Page 16

16
18
19
BAG
E2
BAG
E2
103001
M3 Nut Lock
x2
117003
Flange Ball Bearing 3x6x2.5mm
x4
116004R
Ball Bearing 6x10x3mm (Red Rubber Case)
x2
101012
M3x6xT0.6mm
x2
106007
M3x12mm Hex Socket
x2
OH/TP Screw(HT)
105018
M2x6mm Cap Screw
x1
108003
M3x10mm FH/ST HEX Screw
x2
116004R
Ball Bearing 6x10x3mm (Red Rubber Case)
x2
117003
117003
117003
101012
117003
101012
103001
228017
103001
106007
338043
105018
228017
338126
116004R
116004R
118003
338123
338124
PRO TIP:
For some track corner conditions, you may need a big steering angle,
there is an option part SW-338124P will give you the solution.
OPTION:
SW-338124P S35-4/e EVO Series
T7 Aluminum Pro Steering Plate
108003
116004R
116004R
338048
338048
