SWorkz S35-4E - Page 12

12
10
BAG
E1
11
104005
M3x4mm Set Screw
x2
106013
M2.5x8mmH ex Socket OH/TPScrew
x
2
106013
104005
108003
M3x10mm FH/ST HEX Screw
x
228006
108006
338057
340017
108006
106002
108003
106002
M3x10mm Hex Socket OH/TP Screw
x1
108006
M3x8mm FH/ST HEX Screw
x2
2
228001(#11 #12 #13)
Note:
The aluminum front upper arm holder (338057) can o󰀨er either
0° or + -1° kick-up for your front upper arm suspension.
You may use the inserts 228001(#13) to get 0° kick-up
or 228001(#12) to get +-1° for your front upper suspension.
