Spare Part List
Item No. Part Name Item No. Part Name
SW-338060 S35-4 Series BBS System Shock Body (L)(2PC)
SW-338061 S35-4 Series BBS System Shock Body (S)(2PC)
SW-338062 S35-4 Series BBS System Tiefron Coated Shock Shaft (L)(2PC)
SW-338063 S35-4 Series BBS System Tiefron Coated Shock Shaft (S)(2PC)
SW-338064 S35-4 E-Buggy Series T7 Aluminum Lightened Main Chassis
SW-338065 S35-4 E-Buggy Series T7 Aluminum Motor Mount
SW-338066 S35-4 E-Buggy Series T7 Aluminum Center Di Mount (CF)
SW-338067 S35-4 Series Emulsion/Bladder 2 Ways Syatem Shock Cap (2PC)
SW-338068 S35-4 Series T7 Aluminum Shock Stud (L)(2PC)
SW-338070 S35 Series Rear Upper Sus. Arm Ball Stud (2PC)
SW-340003 S35-3 Series Pro-composite Carbon Front Upper Arm Cover Set (1mm)
SW-340015 S35-3E/S35-2E/Apollo Series Carbon Fiber Rear Brace Mount
SW-340016 S35-4 Series Pro-composite Carbon Rear Wheel Hub Adjust Plate (R=L)(2PC)
SW-340017 S35-4 Series Pro-composite Carbon Steering Bellcrank Plate
SW-340018 S35-4E Series Pro-composite Carbon Center Di. Plate
SW-400002 O-ring S5 4.8X1.5
SW-400005 Shock Spring Adjust Nut O-Ring
SW-400009 Shock Boot (L)
SW-400010 Shock Boot (S)
SW-400013 SWORKz Shock Seal O-ring 2x2.7mm (8PC)
SW-400019 S350 New BBS System Shock Spring Adjust Nut O-Ring (4pc)
SW-400020 S350 New BBS System Shock Seal O-Ring (4pc)
SW-400023 S35-4 Series BBS System Seal O-Ring for Emulsion Shock Cap (4PC)
SW-40022 S350 New BBS System Shock Bladder (Medium)
SW-420010 Antenna Cup
SW-510091 SWORKz Origional Logo Sticker (2PC)
SW-610019 S35-3 Series Servo Saver Spring Dusty Protect Sponge (2pc)
SW-610020 S35-3 Series Center Big Bore Plastic Di. Case Gasket (3pc)
SW-610023 S35-4 HET Di. Gasket (0.4T)(4pc)
SW-115004A Servo Saver Spring
SW-115005 Rear Sway Bar 2.8mm
SW-115006 Rear Sway Bar 2.6mm
SW-115008A Front Sway Bar 2.3mm
SW-115019 Body Clip
SW-115035A S35/350 Series Front Sway Bar 2.2mm
SWC-115164 S35 Series Black Competition Front Shock Spring (M3-Dot)(75X1.6X9.0)
SWC-115183 S35-4 Black Competition Front Shock Spring (US3-Dot)(62X1.6X7.75)
SW-116004 Ball Bearing 6x10x3mm (4pc)
SW-116006 Ball Bearing 8x16x5mm (10pc)
SW-116019 Ball Bearing 5x13x4mm (4PC)
SW-117003 Flange Ball Bearing 3x6x2.5mm(2pc)
SW-101004 Washer 3.5X10X0.2mm
SW-101010A M3 Countersunk Washer(GM)
SW-101011 M2.6x6xT0.6mm
SW-101012 M3x6xT0.6mm
SW-101018 SHIM 13x16x0.2mm
SW-101019 SHIM 6.0x10.0x0.2mm
SW-101020A S350 Sries 3mm Countersunk Washers (GM)
SW-101021 M3x8xT0.8mm
SW-101039 Steel Washer 5x12x0.3mm
SW-103001 M3 Nut Lock
SW-103003A Flange M3 Nut Lock (GM)
SW-103004 M2.5mm Nut Lock
SW-104004 M3x3mm Set Screw
SW-104005 M3x4mm Set Screw
SW-104009 M3x16mm Set Screw
SW-104010 M5x4mm Set Screw (Flat Bottom)
SW-104011 M4x4mm Set Screw (Flat Bottom)
SW-105001 M3x8mm Cap Screw
SW-105005 M3x12mm Cap Screw
SW-105006A M3x28mm Cap Screw full thread
SW-105013A M3x25mm Cap Screw
SW-105018 M2x6mm Cap Head Screw (10PC)
SW-105020 M4x10mm Cap Screw (8PC)
SW-106001 M3x8mm Hex Soket OH/TP Screw
SW-106002 M3x10mm Hex Soket OH/TP Screw
SW-106003 M3x16mm Hex Soket OH/TP Screw
SW-106006 M3x20mm Hex Soket OH/TP Screw
SW-106007 M3x12mm Hex Soket OH/TP Screw(HT)
SW-106008 M3x12mm Hex Soket OH/TP Screw
SW-106009 M3x25mm Hex Soket OH/TP Screw
SW-106013 M2.5x8mm 1.5mmHex Soket OH/ST Screw
SW-106015 M3x5mm Hex Soket OH/TP Screw
SW-106020 M2.5x5mm 1.5mmHex Soket OH/ST Screw
SW-106021A S35 Series M4x10mm Hex Soket OH/TP Set Screw
SW-2501097B S35 Series Front Bumper (2PC)
SW-2501121C S35/S350 Series Ball End Set with Shock Plastic Parts
SW-2501122B S35/S350 Series Settring Bellcrank Set 2.0 Set (with Servo Horn)
SW-2503260-01 S353 Series Plastic Wheel Hub Inserts Set
SW-2503260-02 S35-3 Series Plastic Arm Inserts Set
SW-2503260-04 S35-3 Series Plastic Knuckle Inserts Set
SW-2503261A S35-3/GT Series Gear Box Set (Fit 5x13x4mm Ball Bearing)
SW-2503264A S35-3 Series Front Steering Knuckle (Type 2.0)
SW-2503270-01 S35-3 Series Front Upper Arms (2pc)
SW-2503270-02 S35-3 Series Rear Upper Arm Outside Ball Ends (2pc)
SW-2503270-03 S35-3 Series Front Steering Ball Ends (4pc)
SW-228001 S35-4 Series Plastic Inserts Set (2Set)
SW-228002-1 S35-4 Series Plastic Rear Wheel Hub (R=L)(2PC)
SW-228003S S35 Series Integrated Wing Mount Set (Soft Material)
SW-228004 S35-4 Series Plastic Side Guard Set
SW-228005S-F S35-4 Series Front Lower Arm in Soft Material (1PC)
SW-228005S-R S35-4 Series Rear Lower Arm in Soft Material (1PC)
SW-228006 S35 Series Shock End/Body Mount/Ball Ends Set (2Set)
SW-228007 S35-4E Buggy Series Steering Servo Mount/Center Di Mount Plastic Parts
SW-228008BK SWORKz 1/8 O Road Formula 2.0 Race Wing (BK)
SW-200193 Antenna Tube
SW-210046 S350 Series LDS Universal Cross Drive Shaft Set 92.5mm (1pc)
SW-210058 S350 series BBS Shock Seal Kit
SW-210079A S35-4 Plastic Center Big Bore HET Di Case
SW-210091 S35-3W Plastic Front/Rear Big Bore Di Case
SW-258001C-E S35 Series Falcon ST-4 Clean Body Shell (Pre-Cut for EP Buggy)
SW-328001 S35-3/4 Series HET Di. Bevel Gear Set
SW-330015 Pin M2.2x9.9mm
SW-330114A S350 Sseries Servo Saver Post (HC)
SW-330117A S350 Series Knuckle Pivot Ball Washer (GM)
SW-330118A S350 Series Knuckle Pivot Ball Nut (GM)
SW-330119 Front Upper Arm HingPin
SW-330121B S350 Wheel Hub (L4.5mm)(HC)
SW-330122A S350 Wheel Nut (HC)
SW-330123A S350 EVO Rear Upper Sus. Arm Turnbuckles M5x38mm
SW-330124 Pin M3.0x16.8mm
SW-330125 Rear Upper Sus. Arm Ball Stud
SW-330126A S350 EVO Steering Turnbuckle M4x40mm
SW-330134 Shock Ball Stud 6mmxL6.7
SW-330136 Sway Bar Ball Stud
SW-330138B S350 Series Aluminum Shock Cap Stud (-1.3mm)(2PC)
SW-330243 SWORKz 3x18mm Shock Hex Screw Set (Anti-Clockwise)
SW-330245 SWORKz 1/8 Motor Pinion Gear 15T
SW-330252 S350 BX1/BR1 Steering Knuckle Pivot Ball Turnbuckle
SW-330557 S350 New BBS System Shock Seal Cap (GM)
SW-330560B S35 New BBS System Shock Spring Adjust Nut (BK)
SW-330562A S35 Series BBS System Shock Piston 1.3mmX6 Holes (BK)(2PC)
SW-330563A S35 Series BBS System Shock Piston 1.4mmX6 Holes (BK)(2PC)
SW-330661A S35-T/S35 Series Competition Center Drive Join (5mm set screw)
SW-330694A S35 E Series 6mm Steel Ball Stud
SW-330697 S35-2E Center Rear Drive Shaft (S)
SW-330699B S35-2E/3E Center Main Drive Shaft (L)
SW-330777A S35-4 Series Steering Linkage Ball Stud 7mm(L7)(4PC)
SW-330782 S35-3 Series Rear Hub Carriers Hinge Pin
SW-338011 S35-3 series Pinion Gear Stopper (5x7x5.1mm)(4PC)
SW-338014 S35-3W T-7075AL Rear Lower Fully Adjustable Toe-In Block(3 degree)
SW-338023 S35-3W Pinion Gear 13T
SW-338024 S35-3W Crown Gear 43T
SW-338025 S35-4 HET Bevel Gear Shaft (2pc)
SW-338027 S35-4 Front/Rear HET Di. Outdrive (2pc)
SW-338028 S35-4 Center HET Di. Outdrive (2pc)
SW-338038A S35-3E/S35-2E/Apollo Series T7075 Roll Bar Brace
SW-338039 S35-3/4 Series Center HET Spur Gear (46T)
SW-338043 S35-3/4 Series Servo Saver Nut with Screw Fixed
SW-338048 S35-4 Series Servo Saver Shaft(2PC)
SW-338049 S35-4 Series T7 Aluminum Rear Front Lower Suspension Plate (RF)
SW-338050 S35-4 Series T7 Aluminum Rear Shock Tower
SW-338051 S35-4 Series T7 Aluminum Steering Knuckle Plate (R=L)
SW-338052 S35-4 Series T7 Aluminum Settring Bellcrank Upper Part-A (with 2Hole)
SW-338053 S35-4 Series T7 Aluminum Steering Plate
SW-338054 S35-4 Series T7 Aluminum Front Shock Tower
SW-338056 S35-4 Series Lower Arm Hinge Pin (68.5mm)(2pc)
SW-338057 S35-4 Series T7 Aluminum Front Upper Arm Holder
SW-338058 S35-4 Series T7 Aluminum Front Lower Arm Plate (FF)
SW-338059 S35-4 Series T7 Aluminum Front Lower Arm Holder (FR)
