SWorkz S35-4E - Parts Number List

36
Parts No. List
Part No. Part Name Q`ty in Use ltem No. Part No. Part Name Q`ty in Use ltem No.
210091 S35-3W Plastic Front/Rear Big Bore Di Case 2 SW-210091
210079A S35-4 Plastic Center Big Bore HET Di Case 1 SW-210079A
2501097B S35 Series Front Bumper 1 SW-2501097B
2501121C S35/S350 Series Ball End Set with Shock Plastic Parts 2 SW-2501121C
2501122B S35/S350 Series Settring Bellcrank Set 2.0 Set (with Servo Horn) 1 SW-2501122B
2503221BK S35-2E/3E Series Black Plastic Radio Box/Battery Case 1 SW-2503221BK
2503260-01 S35-3 Series Plastic Wheel Hub Inserts Set 1 SW-2503260-01
2503260-02 S35-3 Series Plastic Arm Inserts Set 1 SW-2503260-02
2503260-04 S35-3 Series Plastic Knuckle Inserts Set 1 SW-2503260-04
2503261A S35-3/GT Series Gear Box Set (Fit 5x13x4mm Ball Bearing) 2 SW-2503261A
2503264A S35-3 Series Front Steering Knuckle (Type 2.0) L 1 SW-2503264A
2503270-1 S35-3 Series Front Upper Arms 2 SW-2503270-1
2503270-2 S35-3 Series Rear Upper Arm Outside Ball Ends 4 SW-2503270-2
2503270-3 S35-3 Series Front Steering Ball Ends 2 SW-2503270-3
228001 S35-4 Series Plastic Inserts Set 2 SW-228001
228002-1 S35-4 Series Plastic Rear Wheel Hub (R=L) 2 SW-228002-1
228003S S35 Series Integrated Wing Mount Set (Soft Material) 1 SW-228003S
228004 S35-4 Series Plastic Side Guard Set 1 SW-228004
228005S-F S35-4 Series Front Lower Arm in Soft Material 2 SW-228005S-F
228005S-R S35-4 Series Rear Lower Arm in Soft Material 2 SW-228005S-R
228006 S35 Series Shock End/Body Mount/Ball Ends Set 2 SW-228006
228007 S35-4E Buggy Series Steering Servo Mount/Center Di Mount Plastic Parts 1 SW-228007
228008BK SWORKz 1/8 O Road Formula 2.0 Race Wing (BK) 1 SW-228008BK
210058 S350 New BBS System Shock Seal Washer 3.6X7X2.5mm 8 SW-210058
210058 S350 New BBS System Shock Seal Washer 3.5X7X1.0mm 4 SW-210058
210046 S350 Series LDS Universal Cross Drive Shaft Set 92.5mm (1pc) 4 SW-210046
200193 Antenna Tube 1 SW-200193
258001C-E S35 Series Falcon ST-4 Clean Body Shell (Pre-Cut for EP Buggy) 1 SW-258001C-E
328001 S35-3W Di. Bevel Gear 20T 6 SW-328001
328001 S35-3W Di. Bevel Gear 10T 12 SW-328001
330015 Pin M2.2x9.9mm 6 SW-330015
330114A S350 Sseries Servo Saver Post (HC) 1 SW-330114A
330117A S350 Series Knuckle Pivot Ball Washer (GM) 2 SW-330117A
330118A S350 Series Knuckle Pivot Ball Nut(GM) 4 SW-330118A
330119 Front Upper Arm HingPin 2 SW-330119
330121B S350 Wheel Hub (L4.5mm) (HC) 4 SW-330121B
330122A S350 Wheel Nut (HC) 4 SW-330122A
330123A S350 EVO Rear Upper Sus. Arm Turnbuckles M5x38mm 2 SW-330123A
330124 Pin M3.0x16.8mm 4 SW-330124
330125 Rear Upper Sus. Arm Ball Stud 2 SW-330125
330126A S350 EVO Steering Turnbuckle M4x40mm 2 SW-330126A
330134 Shock Ball Stud 9 SW-330134
330136 Sway Bar Ball Stud 4 SW-330136
330138B S350 EVO Aluminum Shock Cap Stud (-1.3mm) 2 SW-330138B
330243 SWORKz 3x16mm Shock Hex Screw Clockwise 2 SW-330243
330244 SWORKz 3x16mm Shock Hex Screw Anti-Clockwise 2 SW-330243
330245 BE1 Motor Gear 15T 1 SW-330245
330252 S350 BX1/BR1 Steering Knuckle Pivot Ball Turnbuckle 4 SW-330252
330557 S350 New BBS System Shock Seal Cap (GM) 4 SW-330557
330560B S35 New BBS System Shock Spring Adjust Nut (BK) 4 SW-330560B
330661A S35-T/S35 Series Competition Center Drive Join (5mm set screw) 2 SW-330661A
330562A S350 New BBS System Shock Piston 1.3mmX6 Holes (BK) 2 SW-330562A
330563A S350 New BBS System Shock Piston 1.4mmX6 Holes (BK) 2 SW-330563A
330694A S35 E Series 6mm Steel Ball Stud 1 SW-330694A
330697 S35-2E Center Rear Drive Shaft (S) 1 SW-330697
330699B S35-2E/3E Center Main Drive Shaft (L) 1 SW-330699B
330777A S35-4 Series Steering Linkage Ball Stud 7mm (L7) 4 SW-330777A
330782 S35-3 Series Rear Hub Carriers Hinge Pin 2 SW-330782
338011 S35 series Pinion Gear Stopper (5x7x5.1mm) 2 SW-338011
338014 S35-3W T-7075AL Rear Lower Fully Adjustable Toe-In Block (3 degree) 1 SW-338014
338023 S35-3W Pinion Gear 13T 2 SW-338023
338024 S35-3W Crown Gear 43T 2 SW-338024
338025 S35-3W Bevel Gear Shaft 6 SW-338025
338027 S35-3W Front/Rear Di. Outdrive 4 SW-338027
338028 S35-3W Center Di. Outdrive 2 SW-338028
338038A S35-3E/S35-2E/Apollo Series Roll Bar Brace 1 SW-338038A
338039 S35-3/4 Series Center HET Spur Gear (46T) 1 SW-338039
338043 S35-3/4 Series Servo Saver Nut with Screw Fixed 1 SW-338043
338048 S35-4 Series Servo Saver Shaft 2 SW-338048
338049 S35-4 Series T7 Aluminum Rear Front Lower Suspension Plate (RF) 1 SW-338049
338050 S35-4 Series T7 Aluminum Rear Shock Tower 1 SW-338050
338051 S35-4 Series T7 Aluminum Steering Knuckle Plate (R=L) 2 SW-338051
338052 S35-4 Series T7 Aluminum Settring Bellcrank Upper Part-A (with 2Hole ) 1 SW-338052
338053 S35-4 Series T7 Aluminum Steering Plate 1 SW-338053
338054 S35-4 Series T7 Aluminum Front Shock Tower 1 SW-338054
338056 S35-4 Series Lower Arm Hinge Pin (68.5mm) 4 SW-338056
338057 S35-4 Series T7 Aluminum Front Upper Arm Holder 1 SW-338057
338058 S35-4 Series T7 Aluminum Front Lower Arm Plate (FF) 1 SW-338058
338059 S35-4 Series T7 Aluminum Front Lower Arm Holder (FR) 1 SW-338059
338060 S35-4 Series BBS System Shock Body (L) 2 SW-338060
338061 S35-4 Series BBS System Shock Body (S) 2 SW-338061
338062 S35-4 Series BBS System Teon Coated Shock Shaft (L) 2 SW-338062
338063 S35-4 Series BBS System Teon Coated Shock Shaft (S) 2 SW-338063
338064 S35-4 E-Buggy Series T7 Aluminum Lightened Main Chassis 1 SW-338064
338065 S35-4 E-Buggy Series T7 Aluminum Motor Mount 1 SW-338065
338066 S35-4 E-Buggy Series T7 Aluminum Center Di Mount (CF) 1 SW-338066
338067 S35-4 Series Emulsion/Bladder 2 Ways Syatem Shock Cap 4 SW-338067
338068 S35-4 Series T7 Aluminum Shock Stud (L) 2 SW-338068
338070 S35 Series Rear Upper Sus. Arm Ball Stud 2 SW-338070
340003 S35-3 Series Pro-composite Carbon Front Upper Arm Cover Set (1mm) 2 SW-340003
340015 S35-3E/S35-2E/Apollo Series Carbon Fiber Rear Brace Mount 1 SW-340015
340016 S35-4 Series Pro-composite Carbon Rear Wheel Hub Adjust Plate (R=L) 4 SW-340016
340017 S35-4 Series Pro-composite Carbon Steering Bellcrank Plate 1 SW-340017
340018 S35-4E Series Pro-composite Carbon Center Di. Plate 1 SW-340018
400002 O-ring S5 4.8X1.5 6 SW-400002
400005 Shock Spring Adjust Nut O-Ring 4 SW-400005
400006 shock seal O-Ring 8 SW-210058
400009 Shock Boot (L) 2 SW-400009
400010 Shock Boot (S) 2 SW-400010
400013 S104 Shock Seal O-ring 2x2.7mm 4 SW-400013
400019 S350 New BBS System Shock Spring Adjust Nut O-Ring 4 SW-400019
400020 S350 New BBS System Shock Seal O-Ring 4 SW-400020
400022 S350 New BBS System Shock Bladder (Medium) 4 SW-40022
400023 S35 Series BBS System Seal O-Ring for Emulsion Shock Cap 4 SW-400023
420010 Antenna Cup 1 SW-420010
510080A SWORKz 1/8 O Road Formula Race Wing Decal 1 SW-228008BK
510091 SWORKz Origional Logo Sticker 1 SW-510091
518002 S35-4E Body Decal Sheet 1 SW-258001C-E
518003 S35 Series Falcon ST-4 Clean Body Shell Window Mask 1 SW-258001C-E
610019 S35-3 Series Servo Saver Spring Dusty Protect Sponge 1 SW-610019
610020 S35-3 Series Center Big Bore Plastic Di. Case Gasket 1 SW-610020
610023 S35-3W Di. Gasket (0.4T) 2 SW-610023
115004A Servo Saver Spring 1 SW-115004A
115005 Rear Sway Bar 2.8mm 1 SW-115005
115006 Rear Sway Bar 2.6mm 1 SW-115006
115008A Front Sway Bar 2.3mm 1 SW-115008A
115019 Body Clip 2 SW-115019
115035A Front Sway Bar 2.2mm 1 SW-115035A
115164 S35 Series Competition Black Line Front Shock Spring (3 Dot)(75X1.6X9.0) 2 SWC-115164
115183 S35-4 Black Competition Front Shock Spring (US3-Dot)(62X1.6X7.75) 2 SWC-115183
116004 Ball Bearing 6x10x3mm 4 SW-116004
116006 Ball Bearing 8x16x5mm 14 SW-116006
116019 Ball Bearing 5x13x4mm 4 SW-116019
117003 Flange Ball Bearing 3x6x2.5mm 4 SW-117003
101004 Washer 3.5X10X0.2mm 12 SW-101004
101010A M3 Countersunk Washer (GM) 4 SW-101010A
101011 M2.6x6xT0.6mm 4 SW-101011
101012 M3x6xT0.6mm 4 SW-101012
101018 SHIM 13x16x0.2mm 12 SW-101018
101019 SHIM 6.0x10.0x0.2mm 1 SW-101019
101020A S350 Sries 3mm Countersunk Washers (GM) 5 SW-101020A
101021 M3x8xT0.8mm 2 SW-101021
101039 Steel Washer 5x12x0.3mm 6 SW-101039
103001 M3 Nut Lock 17 SW-103001
103003A Flange M3 Nut Lock (GM) 5 SW-103003A
103004 M2.5mm Nut Lock 4 SW-103004
104004 M3x3mm Set Screw 4 SW-104004
104005 M3x4mm Set Screw 4 SW-104005
104009 M3x16mm Set Screw 1 SW-104009
104010 M5x4mm Set Screw (Flat Bottom) 6 SW-104010
104011 M4x4mm Set Screw (Flat Bottom) 1 SW-104011
105001 M3x8mm Cap Screw 1 SW-105001
105005 M3x12mm Cap Screw 2 SW-105005
105006A M3x28mm Cap Screw full thread 2 SW-105006A
105013A M3x25mm Cap Screw 2 SW-105013A
105018 M2x6mm Cap Head Screw 1 SW-105018
105020 M4x10mm Cap Screw 2 SW-105020
106001 M3x8mm Hex Soket OH/TP Screw 1 SW-106001
106002 M3x10mm Hex Soket OH/TP Screw 12 SW-106002
106003 M3x16mm Hex Soket OH/TP Screw 4 SW-106003
