SWorkz S35-4E - Page 14

14
15
14
BAG
E1
228001(#2 #3 #4)
228001(#2 #3 #4)
106002
338050
228006
108001
M3x12mm FH/ST HEX Screw
x4
108001
108008
M3x35mm FH/ST HEX Screw
x2
338056
338056
108008
106002
M3x10mm Hex Socket OH/TP Screw
x1
338056
S35-4 Series Lower Arm Hinge Pin (68.5mm)
x2
PRO TIP:
The S35-4 Aluminum Rear Lower Fully
Adjustable Toe-In Block (338014) can use 3
types of square inserts to get 1.0/2.0/3.0 3
different toe in angles. Also plus 3 different
rear lower arm kick up degrees.
338014
OPTION:
228001-2 S35-4 Series Rear Lower Arm Holder Square Insert (+1/+1)
228001-3 S35-4 Series Rear Lower Arm Holder Square Insert (0/+1)
228001-4 S35-4 Series Rear Lower Arm Holder Square Insert (0)
