SWorkz S35-4E - Page 19

19
24
BAG
E3
103001
103001
330782
330782
330782
Rear Hub Carriers Hing Pin with Nut
x2
103001
M3 Nut Lock
x2
25
330125
330123A
Rear Upper Sus. Arm Turnbuckles
x2
338070
330123A
9.85mm9.85mm
2503260
(#6 #7)
2503260 (#6 #7)
2503260 (#6 #7)
2501121C
2501121C
22.85 mm22.85 mm
Longer Upper Arm Linkage Set-up
Shorty Upper Arm Linkage Set-up
228006-5
