SWorkz S35-4E - Page 22

22
30
31
BAG
F
106008
228007
340018
338066
330245
106006
106008
228007
228007
338066
108012
106006
104011
750 BL Motor
is not included
3mm hole
4mm hole
106002
M3x10mm Hex Soket OH/TP Screw
x2
104011
M4x4mm Set Screw (Flat Bottom)
x1
108012
105020
108012
M4x16mm FH/ST HEX Screw
x4
106024
M4x12mm Hex Soket OH/ST Screw
x2
105020
M4x10mm Cap Screw
x2
106008
M3x12mm Hex Soket OH/TP Screw
x2
106006
M3x20mm Hex Soket OH/TP Screw
x2
106002
106024
PRO TIP:
Not only use 105020
(M4x10mm Cap Screw )
but there is also included
105012(M3x10mm Cap
Screw) for lock on your
BL motor.
108003
M3x10mm FH/ST HEX Screw
x2
340015
108003
