SWorkz S35-4E - Page 26

26
BAG
F
101012
101012
39
38
228006
330134
200603
228006
108006
108003
104009
330694A
108003
106008
106008
2503221BK
104009
M3x16mm Set Screw
x1
108003
M3x10mm FH/ST
x1
108003
M3x10mm FH/ST
x3
108006
M3x8mm FH/ST HEX Screw
x1
103001
M3xNut Lock
x1
101012
M3x6xT0.6mm
x4
228007
106008
103001
108003
Assembly Note:
According to di󰀨erent brands servo, you can
use di󰀨erent servo hold inserts and screws to
adjust your servo position.
106008
M3x12mm Hex Soket OH/TP Screw
x4
Servo is not
included in the kit.
106008
M3x12mm Hex Soket OH/TP Screw
x1
0mm
