GOLIATH JUNIOR III GOLIATH JUNIOR III
SPECIFICATIONS
Description: 2x10 + Tweeter Speaker Enclosure
Power Handling: 350 watts RMS
Impedance: 8 ohms or 4 ohms – depending upon which
model puchased (8-ohm and 4-ohm models available)
Frequency Response & SPL: 105 dB SPL @ 1W1M
(–3 db @ 45 Hz and 12 kHz)
Speaker Complement: (2) 10" PAS Drivers, (1) Foster Horn
Porting: Front Slot Port
Dimensions: 23"W x 15.75"H x 16.5"D
Weight: 55 lbs.
P.A.S. 10" SPEAKER SPECIFICATIONS
Free Air Resonance: 47Hz
Individual Impedance: 8 Ohms (each)
Power Rating: 175 Watts RMS (each)
CONNECTION AND OPERATION
The SWR Goliath Junior III can be connected to any musical instrument amplifier capable of driving
a 4 or 8 ohm load. To connect your amplifier to Goliath Junior III, run a high quality speaker cable (18
gauge or heavier) from your amplifier’s speaker output to one of the designated speaker inputs
(Speakon or 1/4") on Goliath Junior III’s input panel.
POWER HANDLING
The power output rating for any amplifier that is connected to Goliath Junior III should not exceed the
enclosure’s 350 watt RMS power handling capacity. Please be aware that exceeding Goliath Junior III’s
power handling capacity can void the SWR warranty if any damage occurs to your loudspeakers due to
overpowering.
FULL RANGE INPUT AND OUTPUT JACKS
Goliath Junior III features four, full range input/output jacks (two standard 1/4" and two Speakon) wired
in parallel. If you are running two speaker enclosures in parallel, connect the speaker cable from your
amplifier to either jack labeled “IN,” and a second speaker cable from either jack labeled “OUT” to the
input of the second speaker enclosure.
TWEETER ATTENUATOR CONTROL
The large dial found on the input panel of the cabinet is the Tweeter Attenuator. This control is used to
adjust the level of high frequency signal present at the tweeter. A normal setting for this control is
straight up or “twelve o’clock.” Turning the dial fully counter-clockwise removes the tweeter from the cir-
cuit. As you turn the dial clockwise from this position, the high frequency content is increased.
INTERNAL CROSSOVER
Goliath Junior III’s internal (passive) crossover divides the incoming signal into two frequency bands. The
crossover point is 5 kHz (frequencies above 5 kHz are sent to the tweeter, frequencies below 5 kHz are
sent to the 10" speakers).
8-ohm model
4-ohm model
10 • BASS SPEAKER ENCLOSURES OWNER’S MANUAL
