SWR SM-500 User Manual

SM-500 • 19
AC FUSE
7 AMP
SLO BLO
120 VOLTS
50/60 HZ
840 WATTS
FUSE
LEFT SPEAKER
RIGHT SPEAKER
L SPKR
FUSE
8 AMP
R SPKR
FUSE
8 AMP
SPEAKER OUTPUTS
250W X2
STEREO
1
2
1
2
BRIDGE
400W MONO
FUSE
FUSE
EFFECTS
STEREO
EFFECTS RETURN
L
EFFECTS
SEND
R
MONO
BALANCED OUT
TUNER OUT
XLR PAD
PULL GND
LIFT
MIN
MAX
SM-500 STEREO EFFECTS PATCHING DIAGRAM
Power Amp Assign Switch set to “Stereo” position.
Speaker 1
Speaker 2
Note: Use Shielded Patch Cable for all Effects Loop connections.
Stereo Effects Unit
Left Out
Mono In
Right Out
LINE
DIRECT
